Optimus Prime

AHT16 Series Light Tower

With a powerful brightness of up to 1008,000 Lumens, it replaces the function of three traditional lamps with just one, yet only at the cost of two. This unique design not only optimizes the lighting effect but also shows excellent cost-effectiveness, providing an efficient and economical solution for your lighting needs.

Contact Us Today To Discuss Your Requirements

Mobile lighting

AHT16 Series Light Tower

Mast System

Max. mast height: 15,850mm ( 52′)

Mast structure treatment: Hot galvanizing

Mast raise: Hydraulic

Mast telescope: Hydraulic

Light bar rotation: Electric 340 °

Luminaire

Luminaire: 6*1200 W LED

Overall lumens: 1008,000 Lumens

Towing Dimensions

Overall length: 8,490mm ( 27’10”)

Overall width: 2,285mm ( 7′ 6″ )

Overall height: 2,325mm ( 7’7½ )

Chassis

Structure: Fully bunded chassis metal strcture

Structure treatment: Hot galvanazing

Brake: Hydraulic

Towing frame: “I” style with heavy duty jack & safe chains

Stabilizing leg: Hydraulic legs

Whee: R16 off road tyres with 6 studs rim

Towing coupler:

75mm pintle ring or 50mm ball coupler

Wheel chocks with pocket: 2 kits

Tail lights: LED tail lights and road registrable features

Max. towing speed: 100km/h ( 62 mph)

General Data

Fuel tank: 270liters (71 US gal) bunded metal tank

Control system: ALC708

Jump start receptacle: 350 A

Max. wind resistance: 100km/h (62mph)

Acoustic pressure: 69 dB(A) at 7 meters away

Max. units load in 40′ HC: 1

Applications (Sports Areas)

AIKO Lighting is a professional-grade sports lighting manufacturer for indoor or outdoor sports lighting applications. The low glare optics helps to make an enjoyable environment for players and spectators. Switching to LED luminaires is a great retun on your investment , with up to 60% of energy-savings compared with metal halides or HID. Quick installation and labor cost-saving solution. Flexible mounting solutions of different types of brackets.
